NATO Cockpits and Interiors (1947-Current)
USAF aircraft in the early post-war period were most commonly painted in two sheens of black. Instrument panels received the aptly named, semi-gloss ANA 514 Instrument Black (later FS 27038) whereas all other sections of the cockpit received the flat ANA 604 Black (later FS 37038) to help reduce reflections. However, it was not uncommon for some sections to be painted in the myriad of interior greens that were used during World War II and which varied between aircraft and manufacturer (see the USAAF page for more information). In November 1953, the order was given to factory paint cockpits on all newly-built US aircraft of all branches in ANA 621 Dark Gull Gray (later FS 36231). Further details were specified under MIL-C-8779(ASG) dated 7 July 1955 which also called for instrument bezels, mounting flanges, and adjustment knobs to be painted ANA 604 (FS 37038), resulting in a fully non-spectacular (flat) cockpit. This standard has remained in place to this day and has even been adopted on many NATO multi-national aircraft such as the Tornado and Eurofighter given that many of the partner countries use FED-STD colors as well.
ANA 621 | ANA 604 | ANA 511 | ANA 512 | |
FS 36231 | FS 37038 | FS 17875 | FS 16473 | |
Dark Gull Gray | Black | Insignia White | Aircraft Gray | |
Scheme | ||||
Standard | Cockpit | Instruments | Interiors | (Wheel Wells) |
Color matches | ||||
Gunze Mr. Color | C317 | C33 | C316 | C73 |
Gunze Mr. Hobby | H317 | H12 | H316 | H57 |
Humbrol | 140 | 33 | – | – |
Italeri | 4755AP | 4768AP | 4696AP (!) | – |
Model Master | 1740 | 1749 | 1745 | 1731 |
Revell | – | 08 | – | – |
Tamiya Acrylic | (XF-54) | XF-1 | – | – |
Tamiya Lacquer | – | LP-3 | LP-34 | – |
Vallejo Model Air | 71.277* | 71.057 | 71.279* | 71.335** |
Vallejo Model Color | 70.991 | 70.950 | – | – |
AKAN | 62009 | 78003 | – | 6/72027 |
AK 3Gen Acrylic | AK11884 | AK11029 | AK11868 | AK11867 |
AK Real Colors | RC916 | RC804 | RC891 | RC890 |
AMMO by Mig | A.MIG-205** | A.MIG-046 | – | – |
Hataka | HTK-_044* | HTK-_041 | HTK-_043 | HTK-_045 |
Lifecolor | UA 033 | LC 02 | UA 148 | UA 041 |
Mission Models | MMP-064 | MMP-047 | MMP-104 | MMP-102 |
Mr. Paint | MRP-100 | MRP-5 | MRP-99 | MRP-242 |
Xtracolor | X131 | X404 | X141 | X138 |
Xtracrylix | XA1131 | – | XA1141 | XA1138 |
